DIABOLO 400 LC | ACME LIGHTING

主要特征

7 x 50W RGBW LEDs

光源

20,000 小时

光源预期使用寿命

6,170 lumens

灯具光通量

4.5°-37°

光束角度

9°-57°

光斑角度

2,500K – 8,000K

线性CTO色温调节

6.0 kg (13.2 lbs)

灯具重量

功能概述

WASH 400 RGBL 由7颗50W RGBL四色LED作为发光光源，新增独立色彩通道，拓展色域范围、提升色彩饱和度，混色衔接顺滑自然，赋予舞台鲜活绚丽的光影表现。集光束与染色一体化功能，搭载电动线性变焦结构，可瞬时在锐利聚束与均匀铺光之间切换。

灯具高光输出可达6170流明，两米距离照度108,100lux，亮度充沛、画面表现力出众；2500K-8000K连续可调CTO色温，轻松适配多样场景氛围。搭配高能频闪、均匀混色与丰富内置色彩程序，轻松塑造灵动多变的动态灯光。

WASH 400 RGBL机身紧凑小巧，运转流畅稳定，广泛适配酒吧夜店、固定安装等场景，依托升级色彩性能与强劲光效，是需要营造氛围感场地的优选舞台灯具。

技术参数

型号

产品型号: DIABOLO 400 LC
Model Code: WASH 400 RGBL

T/CETA001-2021标准型号

W-LED350C4/D20

光源

光源: 7 x 50W RGBW LEDs
灯具光通量:
- 自动模式: 6,170 lumens
- 安静模式: 4,540 lumens
- 超安静模式: 4,280 lumens
光源预期使用寿命: 20,000小时*
*数据由光源供应商提供

光学系统

光束角度: 4.5°-37°
光斑角度: 9°-57°

控制与程序

4 个触摸按键
控制面板: OLED显示屏
控制协议: DMX512，RDM
DMX 通道模式: 4
控制通道: 17/19/25/29
软件升级: 通过DMX连接升级软件

X轴/Y轴

X轴运转角度: 540°
Y轴运转角度: 230°
X轴/Y轴位置失步自动校正
X轴/Y轴精度扫描: 16 bit

颜色盘

线性CTO色温调节: 2,500K-8,000K

其他效果

多种速度频闪效果
0-100%顺滑调光
电动调焦系统
卓越的色彩宏效果
均匀RGBL混色系统

电气与接口

输入电压范围: 180-240Vac; 50/60Hz
功率: 365W
电源插座: 电源连接器输入/输出
信号输入/输出: 3芯或5芯卡侬头插座

灯具规格

灯具尺寸:
- 宽: 170 mm (6.7")
- 深: 217 mm (8.5")
- 高: 345 mm (13.6")
- 净重: 6.0 kg (13.2 lbs)

包装规格

纸箱尺寸:
- 宽: 315 mm (12.4")
- 深: 255 mm (10.0")
- 高: 450 mm (17.7")
- 重量: 7.4 kg (16.3 lbs) (含纸箱, 1装1标准)

工作环境

最高环境温度: 45°C
最低工作温度: 0°C
最高表面温度: 65°C
防护等级: IP20

噪音数据

自动模式: 56 dB(A) @ 1 m
安静模式: 53 dB(A) @ 1 m
超安静模式: 45 dB(A) @ 1 m

安装

可水平或垂直安装
通用的工作位置
可双灯钩吊挂安装
保险绳连接孔

出厂配置

电子说明书
电源线
灯钩固定板套件(2030008294)

可选购配件(含配件编码)

灯钩: C-100A (2060001635)
保险绳: SW-02 (2060000200-B)
信号线: 3芯或5芯信号线

尺寸图

照度图

效果

Beam Angle

Field Angle

资料下载

	版本	查看	下载	更新
灯库下载

展开

收起

可选配件

名称: SW-02

产品码: 2060000200-B

材质: Φ2.5 钢丝

名称: XLR 信号线

名称: C-100A

产品码: 2060001635

最大承重: 100 kg (220.5 lbs)
